Nylon Fully Insulated Female Connector
DESCRIPTION - NYLON FULLY INSULATED FEMALE CONNECTOR
Company Introduction
Yueqing Gaopeng was founded in 2016, Zhejiang Province. We are a professional terminal manufacturer. We have engaged in design，development and production of various electrical terminals and wiring accessories.
We always adhere to the "优品质，迎高朋" business philosophy, which translates to “High-quality connectivity is the gateway to trust".
Our dedication to quality and integrity is unwavering, and we are always striving to provide more superior products to all customers.
Product Introduction
Male and Female Fully Insulated Wire Crimp Terminal Nylon Quick Connectors are made of high quality tin-plated red copper, whose surfaces are plated with tin which ensures good conductivity and corrosion resistance. Spade design allows for quick connection or disconnection.Male/female spade connectors can be easily connected and disconnected, suitable for frequent connections. Matching connector:MDFNY
Works with all types of electrical projects, including home, automotive, scientific, and industrial applications. Quick disconnect terminals are essential for electrical termination and power transfer.
Product Description
Nylon Quick Connectors have a semi-flexible nylon protective cover, It can prevent corrosion,oxidation and short circuit.Translucent nylon protective cover can be used to check wiring accuracy.
Product Specification
Nylon connectors are color coded according to industry standards:
Red terminals for 22-18AWG,,0.5-1.5mm²
Blue terminals for 16-14AWG,1.5-2.5mm²
Yellow terminals for 12-10AWG, 2.5-4mm²
Metal Material: Brass
Maximum Working Temperate: 220°F (105°C)
Maximum Voltage: 400V
Accept a combination of solid and stranded wires
User Guide
Step1:Strip wire insulation about 8-10mm
Step2: insert the wire into electrical wire terminals
Step3: crimp connectors splice barrel with crimping pliers
Step4:the connection is done.
Application
Comply with International standards, perfect for house and automobile applications, whether you are working on your vehicle, home or scientific project, our quick connector wire connectors will ensure sure everything bond correctly
Thick brass in the wire connectors ensures strong secure crimping every time, providing small voltage drop, high current flow, and less heat. These will prevent short circuits and problematic wiring.
Technical Parameters
|
ITEM NO |
Nema Tab |
WIRE SECTION |
DIMENSION mm |
PCS/ PACK |
COLOR |
EXPLANATION | ||||||
| A.W.G | mm² | B | L | E | D | d1 | T | |||||
| FDFNY1.25-250 | 0.8x6.35 | 22-16 | 0.5-1.5 | 11.0 | 24.0 | 10.0 | 4.4 | 1.7 | 0.8 | 500 | Purple | Material:Brass Insulation:Nylon(PA66) Temperature:105℃ Voltage:400V |
| FDFNY2-250 | 0.8x6.35 | 16-14 | 1.5-2.5 | 11.0 | 24.0 | 10.0 | 4.4 | 2.3 | 0.8 | 500 | Green | |
| FDFNY5.5-250 | 0.8x6.35 | 12-10 | 4.0-6.0 | 11.0 | 24.0 | 10.0 | 6.3 | 3.4 | 0.8 | 500 | Yellow | |
| FDFNYA1.25-250 | 0.8×6.35 | 22-16 | 0.5-1.5 | 8.8 | 21.3 | 10.3 | 4.2 | 1.7 | 0.4 | 1000 | Red | |
| FDFNYA2-250 | 0.8x6.35 | 16-14 | 1.5-2.5 | 8.8 | 21.3 | 10.3 | 4.2 | 2.3 | 0.4 | 1000 | Blue | |
| FDFNYA5.5-250 | 0.8x6.35 | 12-10 | 4.0-6.0 | 8.8 | 22.3 | 10.3 | 6.1 | 3.4 | 0.4 | 500 | Yellow | |
